Conrock®
ROCKWOOL Conrock® is a stone wool insulation board designed for use in Sandwich Wall Panel (SWP) applications. Conrock® can be engineered to fit your dimensions and provides excellent thermal and fire resistance properties.
1/2
Popular applications
- OEM insulation
About Conrock®
ROCKWOOL Conrock® is a rigid insulation board designed specifically for application in Sandwich Wall Panel (SWP) systems where excellent thermal and fire resistance properties are required.
Conrock® has excellent sound-dampening properties, is dimensionally stable, vapor permeable and will not encourage the growth of mold. Noncombustible, stone wool does not promote smoke or flame spread when exposed to flame.
- Thermal performance
- Fire resistance
- Noncombustible
- Dimensional stability
Why use stone wool insulation
- Noncombustible and fire resistant, stone wool works to contain a fire and prevent its spread.
- Stone wool provides excellent noise reduction and sound absorption to help you create quieter, more productive environments.
- Easily fabricated, our OEM solutions are versatile to service a variety of applications and help you meet specification and optimize fit for use.
- Durable inorganic material that does not rot or promote the growth of mildew, fungi or bacteria
Applications
- Designed for use in sandwich panel systems.
- Durable insulation for industrial applications.
- Improves installation efficiency and safety in industrial buildings.
Product certificates
Conrock® sizes, dimensions & packaging
Find Conrock® thickness, width, length and pack quantities—everything you need for accurate specification and ordering.
- All
- 1
- 2
- 3
- 4
- 4.1
- 5
- 6
Specifications & testing
Explore Conrock® specifications and test results, based on relevant industry standards.
| Name | Value | Unit | Test standard |
|---|---|---|---|
| Mineral Fiber Block and Board Thermal Insulation | Type IVB Compliant | ASTM C612 | |
| Mineral Fiber Thermal Insulation for Buildings | Type 1 Compliant | CAN/ULC S702 | |
| Flame spread index | 0 | ASTM E84 | |
| Smoke Developed Index | 0 | ASTM E84 | |
| Determination of Non Combustibility of Building Materials | Non-combustible | CAN/ULC S114 | |
| Corrosion of Steel | Passed | ASTM C665 | |
| Density | 8.5 | lbs/ft3 | ASTM C167 |
| Density | 136 | kg/m3 | ASTM C167 |
| R-Value / inch @ 75 °F | 4 | hr.ft².F/Btu | ASTM C518 (C177) |
| RSI value / 25.4 mm @ 24 °C | 0.7 | m²K/W | ASTM C518 (C177) |
| Determination of Fungi Resistance | Passed | ASTM C1338 |
Conrock® technical documents & resources
Download Conrock® technical documents and resources, including the product data sheet, to support accurate specification and efficient project planning.
Conrock_info-technique_fr
CONROCK de ROCKWOOL, isolant pour panneaux sandwich, avec excellente thermicité et pyrorésistance.
